AEH-25 Extra Heavy Duty 28” Lathe Machine is designed for ultra heavy-duty turning, threading and large industrial machining operations. Featuring 1900 mm swing over bed, 154 mm spindle bore, 8 speed gearbox, and 10 HP motor, it delivers maximum rigidity, high torque performance and dependable heavy-duty output.
| Specification | Size |
|---|---|
| Length of Bed | 4250 mm (14 ft) |
| Height of Centre | 700 mm (28") |
| Swing Over Bed | 1900 mm |
| Swing Over Cross Slide | 1760 mm |
| Movement of Cross Slide | 375 mm |
| Swing In Gap | 1400 mm |
| Admit Between Centre | 3300 mm |
| Bed Type | 2V & 2 Flat |
| Bed Width | 750 mm (30") |
| Length of Gap in Bed | 190 x 2 |
| Length of Bed in Front of Face Plate | 190 mm |
| Spindle Nose Thread | 6 T.P.I. 130 |
| Taper Bore in Spindle Sleeve | MT-5 |
| Spindle Bore | 154 mm |
| No. of Speeds | 8 |
| Speed Range | 50–450 RPM |
| Thread Range | 0.02–2 mm |
| Diameter of Screw | 50.8 x 2 T.P.I |
| Metric Threads | 13 (1–6 mm) |
| Inch Threads | 19 (1–24 TPI) |
| Main Motor | 10 H.P. |
